| Max. DC input power (W) |
9000 |
| Max. DC input voltage (V) |
1000 |
| Starting voltage(V)/Min. operation voltage(V) |
220/150 |
| MPPT Range(V)/Rated input voltage(V) |
200-800/610V |
| Number of MPPT/String per MPPT |
2/1 |
| Max. DC current (A) Per MPPT x Number of MPPT |
12X2 |
| DC switch |
Optional |
| Rated output power (W) |
8000 |
| Max. AC output current (A) |
12.5 |
| Grid voltage range |
3/PE,230/400V,(320-460V); 3/PE,220/380V,(320-460V) |
| Grid frequency range |
50Hz(47-51.5Hz) / 60Hz(57-61.5Hz) |
| Power Factor |
-0.8-+0.8(adjustable) |
| THDi |
<3%(at rated power) |
| AC output |
3-phase (L1, L2, L3, N, PE)/(L1, L2, L3, PE) |
| Cooling method |
Natural cooling |
| Max. efficiency |
98.30% |
| Euro-efficiency |
97.80% |
| MPPT efficiency |
99.90% |
| Protection degree |
IP65 |
| Self-consumprtion (at night) |
<0.5(W) |
| Topology |
Transformer less |
| Operating temperature range |
-25 C -+60 C (derate after 45 C) |
| Relative humidity |
0-95%, no condensation |
| Protection |
PV array insulation protection, PV array leakage current protection, Ground fault monitoring, Grid monitoring, Island protection, DC monitoring, Short current protection etc. |
| Display |
2 inches LCD Display, Support Backlit Display |
| Communication interface |
Rs485 (standard) : Wi Fi, GPRS200 (optional) |
| Dimension (H x W x D mm) |
575 x 360 x 150 |
| Weight (kg) |
23 |
| Installation |
Wall mounting |
