KSolare 1 KW/1.2KW Single Phase On-Grid Inverter

KSolare 1 KW/1.2KW Single Phase On-Grid Inverter

Brand: KSolare

Category: Solar Inverter

Approximate Price

₹ 16,870

plus 12% GST

Solar Business Get Additional Discount

Install Solartrade App Today

Solartrade app

Become Our Channel Partner

Grow Your Solar Business or Start New

Product Description

  • The extremely high conversion efficiency of up to 98.7%.
  • TEXAS Quad-core Dual DSP based digital processor.
  • Multi-string technology with an extra-wide MPPT range.
  • Built-in WiFi / GPRS with real-time PV Monitoring.
  • Innovative weak-light power generation technology.
  • User-defined Grid Parameters Controller (V / F / W).
  • Next-generation strong MPPT used.

Technical Description

Input (DC)

Max. DC Power (W) 1200
Max. DC Voltage (Vdc) 450
MPPT Tracking Voltage 70-450
Number of MPPT Tracker / Strings Per MPPT 1
Strings Per MPPT trackers 1/1
Min. Start-up/Shutdown Voltage(V 100 / 150

Output (AC)

Nominal Output Power(W) 1000
Max. Output Power(W) 1100
Nominal Grid Voltage(V)/Range(V) 170 - 270 ( Adjustable )
Nominal Grid Freq/Range(Hz) 47-55 Hz auto-selection
Max. Output Current (A) 5
AC Connection( with PE) Single Phase
THD(%) <2.5%
Power Factor(%) >99.95%

Efficiency

Max. Efficiency (%) 97.6
Max. Euro Efficiency (%) 97.1
Max. MPPT efficiency (%) 99.5

Standards, Safety & Protections

Safety DC Reverse -Polarity & SC Protection, DC/AC side Varistor (Thermally Protected), Grid monitoring & Anti Islanding, Transformer-less Isolation.
Protection Class 1 (According to IEC62103)
Over Voltage Category PVII / Mains II(According to IEC62109-1)
Safety Standard IEC 62109-1&2,IEC 62116
EMC Standard IEC 61000-6-1/2/3/4
Environment Protection IEC 60068-2-1/2/14/15
Ingress Protection IP 65(Accordance to IEC 60529)

Physical Parameters

Dimensions (WxHxD) mm 270x417x124
Weight(kg) 5.2

General Data

Operating Temperature -25 to 60 degree
Night Con.(W) / Noise Level <0.2 / <25dB
Heat Dissipation Natural Convection
RH/Max. Altitude 0% to 98%. No Condensation / <2000 without power derating
Display LED with Mimic Display
Communication Interface RS 485 / WiFi
Standard Warranty 5 Years
