4.3 kw solar rooftop system installed using bifacial 535 wp panels quantity 8 nos, 4.3 kw inverter, and bos.

3.2 kw solar rooftop system installed using 6 nos 535wp bifacial panels, 3.2 kw on grid inverter and balance of system.

3.21 kw solar rooftop system installed at Tarsali vadodara using 535 wp 6 nos bifacial panels, 3.2 kw on grid inverter and balance of system.

5.3 kw solar rooftop system installed

1. 535 Wp 10nos bifacial panels Adani make
2. 5.3 kW on-grid inverter UTL make
3. 17 foot high raised Super structure using 60 X 40 HDGI pipe 80 microns direct mount.
4. DCDB 2 in 2 out using Schneider and elmex switch gear MCB and SPD
5. ACDB using Schneider and elmex switch gear MCB and SPD
6. Polycab make wires used for DC, AC and earthing
7. IP 68 MC4 connector elmex make used
8. Earthing quantity 3 for ac, dc and LA
9. L & T meter used as Net metering

8 KW solar rooftop system installed on 8th floor of private residence building.

• 24 nos of 335 Wp polycrestalline panels waaree make used.
• 8 kw three phase on-grid UTL make inverter used.
• Standard balance of system installed.

4.3 kW solar rooftop system installed

• 535 Wp 8 nos bifacial panels Adani make used.
• 4.3 kW on-grid inverter UTL make used.
• Standard balance of system installed.

6 kW solar rooftop system installed

1. 535 Wp 10 busbar bifacial panels Adani make used.
2. 6 kW on-grid inverter UTL make used.
3. Standard balance of system installed.
